Plastic Hockey Dasher Board System is a modular perimeter enclosure designed for ice hockey rinks, inline hockey areas, training centers, skating schools and multi-purpose indoor sports facilities.
The system combines smooth HDPE or UHMWPE facing panels with galvanized steel or lightweight aluminum supporting frames. Typical overall board heights range from approximately 1000 to 1220 mm, while common module lengths range from 1000 to 2400 mm. Polyethylene facing panels are generally available in thicknesses of approximately 8–15 mm.
Straight sections, curved corners, colored kick plates, top handrails, player gates, equipment entrances and optional transparent shielding can be configured according to the rink layout. Individual panels and frame modules can be inspected, removed or replaced separately.
Plastic Hockey Dasher Board System is a modular perimeter enclosure designed for ice hockey rinks, inline hockey areas, skating schools, hockey training centers and multi-purpose indoor sports facilities.
The connected board modules create a continuous boundary around the playing surface. They help keep hockey pucks and training equipment inside the designated area while separating players from walkways, spectators and surrounding equipment.
The system combines smooth HDPE or UHMWPE facing panels with galvanized steel or lightweight aluminum supporting frames. Straight modules, curved corners, colored kick plates, top handrails, player gates and equipment entrances can be arranged according to the rink layout.
The polyethylene facing panel forms the primary visible and impact-contact surface inside the rink. It provides low water absorption, practical impact resistance, corrosion resistance and a smooth surface that is convenient to clean and inspect.
An ice hockey rink is normally surrounded by low walls known as boards or dasher boards. For a general explanation of rink boards, corners and playing-area construction, visit the Ice Hockey Rink overview on Wikipedia.
Additional information about the plastic material family is available from the Polyethylene overview on Wikipedia.
A Plastic Hockey Dasher Board System is assembled from individual framed barrier modules installed around an ice hockey, inline hockey or compatible multi-sport playing surface.
Straight sections form the long sides and ends of the rink. Curved, segmented or angled modules create smooth corner transitions.
Each module normally includes a polyethylene facing panel, structural metal frame, lower kick plate, top handrail and mechanical connecting hardware.
Adjacent modules can be connected using bolts, locking pins, connecting plates or removable mechanical clamps.
Depending on the installation, the frames can use external triangular supports, wide base feet, removable ballast or fixed floor anchors.
The modular design allows damaged facing panels, kick plates, handrails, gates and complete frame sections to be replaced separately.
The Plastic Hockey Dasher Board System can be manufactured in different dimensions according to the rink size, expected impact and installation method.
The specifications below are practical engineering reference ranges. Final dimensions should be confirmed according to the approved rink and frame drawings.
| Product Name | Modular Plastic Hockey Dasher Board System |
| Facing Panel Material | HDPE or UHMWPE |
| Frame Material | Galvanized steel or aluminum alloy |
| Typical Overall Height | Approximately 1000–1220 mm |
| Low Training Board Height | Approximately 500–800 mm |
| Common Module Length | Approximately 1000–2400 mm |
| Typical Module Length | Approximately 2000 mm |
| Facing Panel Thickness | Approximately 8–15 mm |
| Common HDPE Thicknesses | Approximately 10 or 12 mm |
| Heavy-Duty Panel Option | Approximately 15–20 mm, depending on frame support |
| Kick Plate Height | Approximately 150–250 mm |
| Kick Plate Thickness | Approximately 8–12 mm |
| Top Handrail Width | Approximately 50–100 mm |
| Player Gate Width | Approximately 800–1000 mm |
| Equipment Gate Width | Approximately 1200–1800 mm |
| Standard Facing Color | White |
| Optional Colors | Blue, yellow, red, black or project-specific colors |
| Corner Structure | Curved, segmented or angled modules |
| Installation Type | Permanent, semi-permanent, portable or removable |
| Suitable Environment | Indoor and properly prepared outdoor sports facilities |
The appropriate board height depends on the intended sport and player group. Hockey-style rink boards commonly use greater overall height and stronger supporting frames than low training barriers.
Longer modules reduce the total number of joints. Shorter modules are generally easier to transport, install, dismantle and replace.
Thicker facing panels provide greater rigidity and weight. Thinner panels require closer and more consistent support from the frame.
HDPE is commonly used for hockey dasher-board facing because it provides practical impact resistance, useful rigidity, low water absorption and reliable machining performance.
The smooth white surface creates a clean rink appearance and provides a consistent contact surface when a puck reaches the boards.
HDPE panels can be cut, drilled, countersunk, edge-rounded and installed according to the supporting-frame drawing.
Fasteners should be positioned so that the playing-side surface remains as smooth as possible. Countersunk mounting positions help reduce projecting hardware inside the rink.
HDPE provides a practical balance between performance, panel weight, processing requirements and project cost.
UHMWPE can be selected for areas requiring increased abrasion resistance, strong impact performance and a naturally low-friction surface.
It is suitable for frequently contacted sections, lower wear strips, kick plates and areas exposed to repeated puck or equipment contact.
UHMWPE absorbs very little moisture and maintains useful toughness in cold environments.
The material normally requires additional consideration for dimensional movement, machining tolerances and fastener installation.
The selection between HDPE and UHMWPE should consider expected use, required service life, panel thickness and project budget.
Galvanized steel frames provide strength and stability for permanent or frequently used hockey rink systems.
The protective zinc coating helps reduce corrosion caused by humidity and normal indoor or outdoor exposure.
The frame can include vertical posts, horizontal rails, base plates, triangular supports and connection brackets.
Tube dimensions and wall thickness should be selected according to board height, module length and expected player or puck impact.
Galvanized steel is generally suitable where structural stability is more important than minimum module weight.
Aluminum frames reduce the weight of individual board modules and make repeated installation, dismantling and transportation more convenient.
This option is suitable for seasonal hockey areas, sports exhibitions, shopping centers and multi-purpose venues where the system may be moved regularly.
The aluminum structure must still provide sufficient rigidity for the selected panel dimensions and barrier height.
Reinforcement positions, frame joints and external supports should be confirmed according to the approved project drawing.
Galvanized steel is generally preferred for permanent rinks, intensive hockey training and projects requiring increased structural stability.
Aluminum is generally preferred where lower module weight, frequent transportation and seasonal installation are important.
Selection factors include:
The playing-side surface of the Plastic Hockey Dasher Board System should remain smooth and continuous.
Projecting bolts, exposed metal edges and large height differences between adjacent modules should be avoided.
Plastic panels can use countersunk fixing positions, while selected fasteners can be installed from the rear side of the frame.
The countersink depth should not excessively reduce the remaining material around the mounting hole.
All cut edges should be deburred and finished. Cracked panels or sharp damaged edges should be replaced before continued use.
A replaceable kick plate is normally installed along the lower part of the dasher-board system.
This section receives frequent contact from hockey pucks, sticks, skates and cleaning equipment.
Yellow is commonly selected to create a clear visual transition between the white facing panel and the playing surface.
Blue, red, black and other colors can also be used according to the facility design.
Kick plates can be manufactured from HDPE or UHMWPE and replaced independently when worn.
The top handrail covers and protects the upper edge of the plastic facing panel.
It also creates a finished appearance and makes the rink perimeter easier to identify.
The handrail can be manufactured from HDPE, UHMWPE or another suitable impact-resistant plastic.
Connections between adjacent handrail sections should remain smooth, aligned and secure.
Large gaps, raised joints and exposed sharp edges should be avoided.
Curved corners create a smooth transition between the side and end boards.
They help the puck remain active instead of becoming trapped in a sharp ninety-degree corner.
The system can use purpose-built curved frames or several shorter segmented modules.
The corner radius should be selected according to the total rink dimensions and intended activity.
Each corner section should align accurately with adjacent straight modules.
The Plastic Hockey Dasher Board System can include gates for players, coaches, officials and maintenance personnel.
A typical player or pedestrian gate may provide a clear opening of approximately 800–1000 mm.
Wider equipment entrances may measure approximately 1200–1800 mm, depending on the goals and maintenance equipment that need to enter the rink.
Gate hinges and latches should remain outside the primary playing surface wherever possible.
Each gate should open smoothly, close securely and align with the surrounding board panels.
Acrylic or polycarbonate shielding can be installed above the dasher boards where additional puck containment or spectator separation is required.
The shielding height, thickness and supporting-post arrangement should be selected according to puck speed, rink activity and venue requirements.
Training facilities may use a different protective configuration from professional competition venues.
The shielding, posts, frames and dasher boards should be evaluated as one complete system.
Protective netting can be installed above selected side or end sections, particularly behind hockey goals and shooting areas.
The netting provides additional containment for elevated pucks without using solid transparent panels across the complete height.
Mesh opening, net height, post spacing and tension components should be selected according to the application.
Protective netting is an additional safety component and does not replace the structural dasher boards beneath it.
The modular board system is suitable for:
The barrier system is separate from the refrigerated ice floor and ice-making equipment.
Frames, anchors, gates and access routes should be coordinated with the complete rink design before installation.
The same modular barrier structure can also be used around compatible inline hockey, roller hockey and dry sports surfaces.
The playing floor and dasher-board system should be specified separately.
Flooring should provide suitable wheel grip and flatness, while the barrier should provide impact-resistant panels and a secure supporting structure.
For multi-sport facilities, gate positions and board heights should be selected according to every intended activity.
The Plastic Hockey Dasher Board System can be configured for compact training areas or larger recreational facilities.
These dimensions are project examples rather than official competition specifications.
The final layout should consider corner radius, gates, player areas, equipment access, spectator separation and emergency routes.
A portable dasher-board system uses removable connectors and external supporting feet.
The modules can be dismantled after a sports event or seasonal operating period.
Rubber pads can be placed beneath the support feet to help protect finished indoor flooring.
Freestanding sections may require additional ballast according to the barrier height and site conditions.
Frames, panels, corners and gates can be numbered to simplify future assembly.
A permanent system can be anchored to a prepared concrete foundation or structural rink platform.
Before drilling, refrigeration pipes, drainage systems, electrical cables and other concealed services must be identified.
The supporting floor, anchors, frame structure and plastic panels should be evaluated as a complete system.
The completed barrier should maintain a consistent height and smooth playing-side transition.
Loose hardware, projecting components and unstable supports should be corrected before use.
The plastic facing panels can be cleaned using water, a soft cloth and a suitable neutral cleaning product.
Strong solvents, sharp metal scrapers and aggressive abrasive tools should be avoided.
Routine inspection should include:
Loose hardware should be tightened before continued use.
Cracked panels, unstable frames, damaged gates or broken shielding should be repaired or replaced.
The polyethylene facing panels are cut and machined according to the approved metal-frame drawings.
Plastic processing can include sheet cutting, drilling, countersinking, edge rounding and curved-panel preparation.
Steel or aluminum frames can be produced through profile cutting, welding, drilling, surface treatment and trial assembly.
Important inspection items include:
When selecting a Plastic Hockey Dasher Board System, consider the total rink size, required board height, expected impact and installation frequency.
Facing-panel material, panel thickness, frame material, gate arrangement and anchoring method should also be considered.
HDPE provides a practical balance between impact resistance, rigidity, processing performance and project cost.
UHMWPE can be selected where increased abrasion resistance, impact performance and low-friction characteristics are required.
Permanent and frequently used rinks may prefer galvanized steel frames for increased structural stability.
Temporary and seasonal facilities may prefer aluminum frames or removable galvanized structures for easier handling.
Learn more about our HDPE sheets, UHMWPE panels and engineering-plastic manufacturing capabilities on the Honsee engineering plastic manufacturer website.
The Plastic Hockey Dasher Board System provides a modular, impact-resistant and maintainable rink-boundary solution for ice hockey, inline hockey, training centers and multi-purpose sports facilities.
